TRUCK SCAN TOOLS USB LINK

NEXIQ USB Link 2

PC-to-vehicle interface compatible with multiple software applications, minimizing your investment in multiple brand-specific diagnostic interfaces.

The USB-Link 2, the next generation vehicle interface from NEXIQ Technologies, has arrived. Dependable and rugged, the new USB-Link 2 if five times faster than its predecessor. It has sixteen times more random access memory than the old USB-Link, and it supports heavier bus loads on simultaneous channels.

It also includes a new Bluetooth* module with an enhanced data rate to support wireless communication (500 b/s J1939). For even more reliability, we've upgraded the USB connector to a more robust, automotive grade connector with a latching mechanism. The USB-Link 2 is compatible with a wide range of OEM software applications.

Description

The USB-Link 2, the next generation vehicle interface from NEXIQ Technologies, has arrived. Dependable and rugged, the new USB-Link 2 if five times faster than its predecessor. It has sixteen times more random access memory than the old USB-Link, and it supports heavier bus loads on simultaneous channels.

It also includes a new Bluetooth* module with an enhanced data rate to support wireless communication (500 b/s J1939). For even more reliability, we've upgraded the USB connector to a more robust, automotive grade connector with a latching mechanism. The USB-Link 2 is compatible with a wide range of OEM software applications.

Features:

CAN / J1939 / ISO 15765 - 250K, 500 K, 1M b/s with Auto Baud detection (3 channels)

Single wire CAN (SWCAN)

ISO 11898-3 Fault Tolerant CAN (FTCAN)

J1708

J1850 VPW (Class 2)

J1850 PWM (SCP)

ISO 9141 / KWP2000 (ISO 14230) K/L line

ALDL 9600 and 8192 baud

ATEC 160 baud

Packing List:

NEXIQ USB-Link 2
6-pin/9-pin vehicle Y-adapter
15' USB cable
Quick start reference guide
